Water Jug Problem

water jug problem

Problem Statement

Given two water jugs with capacities X and Y litres. Initially, both the jugs are empty. Also given that there is an infinite amount of water available. The jugs do not have markings to measure smaller quantities.
One can perform the following operations on the jug:

  • Fill any of the jugs completely with water.
  • Pour water from one jug to the other until one of the jugs is either empty or full, (X, Y) -> (X – d, Y + d)
  • Empty any of the jugs

The task is to determine whether it is possible to measure Z litres of water using both jugs. And if true, print any of the possible ways.

Example 1:

  • Input: X = 4, Y = 3, Z = 2
  • Output: {(0, 0), (0, 3), (3, 0), (3, 3), (4, 2), (0, 2)}

Explanation:

  • Fill the 4-litre jug completely with water.
  • Empty water from 4-litre jug into 3-litre  (leaving 1L water in 4L jug and 3L completely full).
  • Empty water from 3L.
  • Pour water from 4L jug into 3L jug (4L being completely empty and 1L water in 3L litre jug)
  • Fill the 4L jug with water completely again.
  • Transfer water from 4L jug to 3L jug, resulting in 2L water in 4L jug.

Example 2:

  • Input:  X = 3, Y = 5, Z = 4
  • Output: 6

Explanation:

  • Fill a 5-litres jug to its maximum capacity.
  • Transfer 3 litres from 5-litre jug to 3-litre jug.
  • Empty the 3-litre jug.
  • Transfer 2-litres from 5-litre jug to 3-litres jug.
  • Fill a 5-litres jug to its maximum capacity.
  • Pour water into a 3L jug from a 5L jug until it’s full.

Breadth-First Search (BFS) Approach

The idea is to run a Breadth-First Search(BFS). The BFS approach keeps track of the states of the total water in both jugs at a given time, The key idea is to visit all the possible states and also keep track of the visited states using a visiting array or a hashmap. In case, the total amount of water in any of the jugs or the summation of the total amount of water in both the jugs is equal to Z, return True and print the resulting states.

Recursion Tree:

Algorithm

  • Initialise a queue to implement BFS.
  • Since, initially, both the jugs are empty, insert the state {0, 0} into the queue.
  • Perform the following state, till the queue becomes empty:
    • Pop out the first element of the queue.
    • If the value of popped element is equal to Z, return True.
    • Let X_left and Y_left be the amount of water left in the jugs respectively.
    • Now perform the fill operation:
      • If the value of X_left < X, insert ({X_left, Y}) into the hashmap, since this state hasn’t been visited and some water can still be poured in the jug.
      • If the value of Y_left < Y, insert ({Y_left, X}) into the hashmap, since this state hasn’t been visited and some water can still be poured in the jug.
    • Perform the empty operation:
      • If the state ({0, Y_left}) isn’t visited, insert it into the hashmap, since we can empty any of the jugs.
      • Similarly, if the state ({X_left, 0) isn’t visited, insert it into the hashmap, since we can empty any of the jugs.
    • Perform the transfer of water operation:
      • min({X-X_left, Y}) can be poured from second jug to first jug. Therefore, in case – {X + min({X-X_left, Y}) , Y – min({X-X_left, Y}) isn’t visited, put it into hashmap.
      • min({X_left, Y-Y_left}) can be poured from first jug to second jug. Therefore, in case – {X_left – min({X_left, Y – X_left}) , Y + min({X_left, Y – Y_left}) isn’t visited, put it into hashmap.
  • Return False, since, it is not possible to measure Z litres.

C++ Code Implementation

typedef pair < int, int > pii;
void printpath(map < pii, pii > mp, pii u) {
  if (u.first == 0 && u.second == 0) {
    cout << 0 << " " << 0 << endl;
    return;
  }
  printpath(mp, mp[u]);
  cout << u.first << " " << u.second << endl;
}
void BFS(int a, int b, int target) {
  map < pii, int > m;
  bool isSolvable = false;
  vector < tuple < int, int, int >> path;
  map < pii, pii > mp;

  queue < pii > q;

  q.push(make_pair(0, 0));
  while (!q.empty()) {

    auto u = q.front();
    q.pop();
    if (m[u] == 1)
      continue;

    if ((u.first > a || u.second > b || u.first < 0 || u.second < 0))
      continue;

    m[{
      u.first,
      u.second
    }] = 1;

    if (u.first == target || u.second == target) {
      isSolvable = true;

      printpath(mp, u);
      if (u.first == target) {
        if (u.second != 0)
          cout << u.first << " " << 0 << endl;
      } else {
        if (u.first != 0)
          cout << 0 << " " << u.second << endl;
      }
      return;
    }
    if (m[{
        u.first,
        b
      }] != 1) {
      q.push({
        u.first,
        b
      });
      mp[{
        u.first,
        b
      }] = u;
    }

    if (m[{
        a,
        u.second
      }] != 1) {
      q.push({
        a,
        u.second
      });
      mp[{
        a,
        u.second
      }] = u;
    }

    int d = b - u.second;
    if (u.first >= d) {
      int c = u.first - d;
      if (m[{
          c,
          b
        }] != 1) {
        q.push({
          c,
          b
        });
        mp[{
          c,
          b
        }] = u;
      }
    } else {
      int c = u.first + u.second;
      if (m[{
          0,
          c
        }] != 1) {
        q.push({
          0,
          c
        });
        mp[{
          0,
          c
        }] = u;
      }
    }
    d = a - u.first;
    if (u.second >= d) {
      int c = u.second - d;
      if (m[{
          a,
          c
        }] != 1) {
        q.push({
          a,
          c
        });
        mp[{
          a,
          c
        }] = u;
      }
    } else {
      int c = u.first + u.second;
      if (m[{
          c,
          0
        }] != 1) {
        q.push({
          c,
          0
        });
        mp[{
          c,
          0
        }] = u;
      }
    }

    if (m[{
        u.first,
        0
      }] != 1) {
      q.push({
        u.first,
        0
      });
      mp[{
        u.first,
        0
      }] = u;
    }

    if (m[{
        0,
        u.second
      }] != 1) {
      q.push({
        0,
        u.second
      });
      mp[{
        0,
        u.second
      }] = u;
    }

  }
  if (!isSolvable)
    cout << "No solution";
}

Java Code Implementation

class Pair {
  int first, second;

  Pair(int f, int s) {
    first = f;
    second = s;
  }
}

void BFS(int a, int b, int target) {
  int m[][] = new int[1000][1000];
  for (int[] i: m) {
    Arrays.fill(i, -1);
  }

  boolean isSolvable = false;
  Vector < Pair > path = new Vector < Pair > ();

  Queue < Pair > q = new LinkedList < Pair > ();
  q.add(new Pair(0, 0));

  while (!q.isEmpty()) {

    Pair u = q.peek();

    q.poll();

    if ((u.first > a || u.second > b ||
        u.first < 0 || u.second < 0))
      continue;

    if (m[u.first][u.second] > -1)
      continue;

    path.add(new Pair(u.first, u.second));

    m[u.first][u.second] = 1;

    if (u.first == target || u.second == target) {
      isSolvable = true;
      if (u.first == target) {
        if (u.second != 0)

          path.add(new Pair(u.first, 0));
      } else {
        if (u.first != 0)

          path.add(new Pair(0, u.second));
      }

      int sz = path.size();
      for (int i = 0; i < sz; i++)
        System.out.println("(" + path.get(i).first +
          ", " + path.get(i).second + ")");
      break;
    }

    q.add(new Pair(u.first, b));
    q.add(new Pair(a, u.second));

    for (int ap = 0; ap <= Math.max(a, b); ap++) {

      int c = u.first + ap;
      int d = u.second - ap;

      if (c == a || (d == 0 && d >= 0))
        q.add(new Pair(c, d));

      c = u.first - ap;
      d = u.second + ap;

      if ((c == 0 && c >= 0) || d == b)
        q.add(new Pair(c, d));
    }

    q.add(new Pair(a, 0));
    q.add(new Pair(0, b));
  }

  if (!isSolvable)
    System.out.print("No solution");
}

Python Code Implementation

def BFS(a, b, target):

    m = {}
    isSolvable = False
    path = []

    q = deque()

    q.append((0, 0))

    while len(q) > 0:

        u = q.popleft()

        if (u[0], u[1]) in m:
            continue

        if u[0] > a or u[1] > b or u[0] < 0 or u[1] < 0:
            continue

        path.append([u[0], u[1]])

        m[(u[0], u[1])] = 1

        if u[0] == target or u[1] == target:
            isSolvable = True

            if u[0] == target:
                if u[1] != 0:

                    path.append([u[0], 0])
            else:
                if u[0] != 0:

                    path.append([0, u[1]])

            sz = len(path)
            for i in range(sz):
                print("(", path[i][0], ",", path[i][1], ")")
            break

        q.append([u[0], b])  # Fill Jug2
        q.append([a, u[1]])  # Fill Jug1

        for ap in range(max(a, b) + 1):

            c = u[0] + ap
            d = u[1] - ap

            if c == a or (d == 0 and d >= 0):
                q.append([c, d])

            c = u[0] - ap
            d = u[1] + ap

            if (c == 0 and c >= 0) or d == b:
                q.append([c, d])

        q.append([a, 0])

        q.append([0, b])

    if not isSolvable:
        print("No solution")

Mathematical Approach

Since we need to find if Z can be measured from the given jugs of X and Y litres. This can be written in a single equation as follows:

A * X + B * Y = Z

where A and B are integers. Now, this is a linear diophantine equation and is easily solvable if. GCD(X, Y) divides Z. So, the conditions to solve this problem are:

  • Z % GCD(X, Y) = 0
  •  X + Y > Z

C++ Code For Mathematical Approach

int gcd(int a, int b) {
  if (b == 0) {
    return a;
  }

  return gcd(b, a % b);
}

bool waterJug(int x, int y, int z) {
  if (x + y < z) {
    return false;
  }

  if (x == 0 and y == 0) {
    if (z == 0) {
      return true;
    } else {
      return false;
    }
  }

  if (z % gcd(x, y) == 0) {
    return true;
  } else {
    return false;
  }
}

Java Code For Mathematical Approach

public class Solution {
  public static int gcd(int a, int b) {
    if (b == 0) {
      return a;
    }

    return gcd(b, a % b);
  }

  public static boolean waterJug(int x, int y, int z) {
    if (x + y < z) {
      return false;
    }

    if (x == 0 && y == 0) {
      if (z == 0) {
        return true;
      } else {
        return false;
      }
    }

    if (z % gcd(x, y) == 0) {
      return true;
    } else {
      return false;
    }
  }
}

Python Code For Mathematical Approach

def gcd(a, b):

    if(b == 0):
        return a

    return gcd(b, a % b)


def waterJug(x, y, z):

    if(x + y < z):
        return False

    if(x == 0 and y == 0):
        if(z == 0):
            return True

        else:
            return False

    if(z % gcd(x, y) == 0):
        return True

    else:
        return False

Practice Question


FAQs

Q.1: What other problems can be solved using the same approach?

Ans: The N-queen problem and the 8-queen problem use the same approach.

Q.2: What is the worst-case and best-case space complexity in the queue approach?

Ans: In the worst case, the queue would contain X * Y distinct states, hence, the space complexity would be O(X * Y). The best space complexity is O(min(X, Y)).
