Technology has empowered mankind with a lot of extraordinary tools and multi-functional devices but it has also come with its own set of challenges. And in today’s fast-paced world, one major concern is the security of our computer system and network. And this problem become even more critical when it comes to big companies. Let’s understand this with an example.
Suppose you have in wifi connection at your home. And you realize that it is running at a faster rate than you are using it. And you doubt that your neighbor has its access. So you decided to discover a number of devices that are connected to this network.
But how will you do that?
By scanning your network through Nmap- a network mapper.
Nmap (“Network Mapper”) is a free and open-source utility for network discovery and security auditing. It is a globally recognized tool mostly used by networking experts and penetration testers to find services, hosts, and open ports on a computer network. Network mapper allows its users to discover which devices are running on the network, find vulnerabilities, and detect installed services.
But before we move ahead, a brief history about Nmap. It was first introduced by network security expert Gordon Lyon in Phrack magazine in September 1997. With its latest release in August 2021, it has evolved very much.
Nmap was originally written in C, C++, Python, and Lua programming languages. It is a widely acknowledged open-source networking tool. Network mapper can run on Windows, Mac OS, Gentoo, and BSD but it is highly popular in Linux.
But why you should learn about it?
So, if you are planning to launch your career in hacking, this revolutionary tool can be super useful to you. And even if your aim is just to expand your cyber security and networks knowledge, knowing the basics of Nmap can be a good idea.
“Fixing a hole is far more effective than trying to hide it. That approach is also less stressful than constantly worrying that attackers may find the vulnerabilities.” But, now the question arises how you can scan your network using Nmap?
To scan your network using Nmap, you have to first install it on your computer. Visit nmap.org and download Nmap for your operating system. And then you can use the appropriate Nmap command to perform the required task.
However, if you are using Kali Linux or parrot OS, it comes pre-installed.
Features of Nmap
- Find security issues – It warns users against external attackers. Nmap scans the server and finds out the path that hackers might use to attack their server.
- Identify open ports– port scanning of target hosts is very easy with the help of Nmap.
- Detect Vulnerabilities – To detect security vulnerabilities in the network, Nmap is the best choice.
- Host discovery – Live hosts in the network can be discovered using Nmap.
- OS Version Detection – Operating system and version detection are also possible through this network mapper.
- Provide crucial information – Nmap also provides additional information such as devices types, reverse DNS (Domain Name System) names, MAC addresses, and IP addresses of all active hosts.
In simple words, Nmap uses IP packets to find out:
- What hosts are part of the network?
- Which operating system they are running?
- What is the size of a network?
Many more such questions can be answered through Nmap scanning.
But before we move to Nmap commands take some tips:
1. Type — help in the terminal and you will get all the options.
2. Network scanning mostly takes a long time, so you have to be patient. You can also use fast mode by typing-F.
So whether you are a college student working on a secret start-up idea, a supreme institute with some confidential data, or a tech giant with sensitive business information, Nmap can safeguard you and your data. You must learn about it.
If you are a beginner with very little knowledge about networks, you can start your Nmap journey by learning commands to scan against hosts or IP addresses like Nmap 184.108.40.206 (scan for the single IP address) and Nmap www.creativity.com (scan for hostname).
Before we moving forward, have a look at Nmap’s basic command format: nmap<scan type><option><target>
Nmap provides commands for almost everything. You just need to have good background knowledge to explore Nmap’s real capabilities.
1. Scan a Range of IP Address
Aim: To scan the entire IP range.
If you wish to scan the entire CIDR(classless inter-domain routing) range of IP addresses, you can use this command.
Command: nmap <IP range>
Example: nmap 220.127.116.11-135 (here IP range is separated by a dash )
In our example, Nmap will scan the IP addresses from 18.104.22.168/24 to 22.214.171.124/24.
2. Port Scanning
Aim: To scan a specific port or entire port range.
Nmap is the best port scanning tool. Performing port scans will provide you with details about port services and states. And not just that Nmap also provides options to scan popular ports and discover open ports. We will see that in the latter section of the article.
Command: nmap -p <numeric value> <IP>
Example: nmap -p 80 192.168.20.128
You can also scan all 65535 ports for your localhost computer by using this command–
nmap -p 1-65535 localhost.
3. Ping Scan Using Nmap
Aim: Host detection
This is one of the most popular and easiest Nmap commands for host detection. If you are interested in knowing which hosts are running in your network, you should use this command. It also provides the option to find out multiple hosts or any specific host. This command returns the IP address and MAC address of available hosts but provides no information about ports. In simple words, it finds all devices in the defined range. And then you can check if there are any IP addresses that you are not familiar with or you can’t account for.
This command sends an ICMP (Internet Control Message Protocol) echo request to all IP addresses of the network. But the major disadvantage of this type of scan is that some remote hosts block IP-based ping packets. Its popular example is– Windows Firewall with advanced security blocks ICMP echoes requests packets by default. This command comes up with details about the host and in comparison to other scannings, it is less aggressive.
Command: Nmap -sP <target>
Example: Nmap -sP 192.168.2.1/24
In the above example, the “-sP” command will scan the list of devices running on the 192.168.2.1/24 subnet.
4. Saving the Nmap Scan Output to a File
Aim: To save the result of the Nmap scan to a file or XML.
Security tool Nmap has become a crucial tool in the cyber security field. And Nmap allows its users to export or save scan results into the text file or XML.
Command: nmap -oN output.txt example.com (This command will export Nmap scan into a text file)
Command: nmap -oX output.xml example.com (This command will save the output of Nmap scanning in XML)
5. Most Popular Ports Scanning
Aim: To scan the fixed number of most popular ports.
In order to apply this command you have to use the “–top-ports” option with a specific numeric value. This option gives you the ability to scan top ports. However, in Nmap, you also have the option to select the number of top ports to scan. This command allows users to get better and faster results.
Command: nmap –top-ports <numeric value> <IP address/Domain>
Example: nmap –top-ports 15 126.96.36.199
In our example, we have used the “–top-ports” option to specify that we need to scan the top 15 ports of the IP address 188.8.131.52
6. Display Open Ports
Aim: To detect open ports.
Finding open ports (target ports that respond to UDP/TCP/SCTP requests) can be the first step to protecting and hacking any network. And if you only want to find ports you can connect to, then this command can be really useful to you.
Command: nmap — open<IP address/domain name>
Example: nmap — open 184.108.40.206
In the above example, we are using “–open” parameter with IP address 220.127.116.11 so that the Nmap command only shows us the ports with the open state.
7. Exclude Host/ IP Addresses for the Scan
Aim: To exclude the host/IP addresses for the scan.
If you want to exclude hosts/ IP address/ network, Nmap provides you with a specific command for this purpose. As the name suggests this command excludes a single target/list of the target from the scan.
Command: nmap <range of IP address> — exclude<IP address to exclude>
Example: nmap 172.16.121.1/24 — exclude 172.16.121.10
In the above example, we are using the “– exclude” command-line option to exclude IP address 172.16.121.10 from the scan.
Note – “–exclude command” accepts single IP address, single host, specific ranges, and whole network.
8. Service Version Detection
Aim: Detection of services.
Nmap has a database of more than 2000 services and associated ports for example– SSH(port 22) and HTTP (port 80). So while doing network inventories if you want to know which versions are running, you can use the Nmap version detection (-sV) command. Knowing the exact version number can be really helpful while finding which exploits your server is vulnerable to.
Command: nmap -sV<IP>
Example: nmap -sV 18.104.22.168
In the above example, we are performing a version scan by using the “sV” command and it will give us a list of services with its versions.
As we have seen, with single Nmap command you can scan your entire network–that’s the power of Nmap. Nmap is an extremely powerful tool. And most importantly, if you want to set your foot hacking world, learning about this tool can be really fruitful for you. It can potentially be used for both white-hat hacking and black-hat hacking. In fact, Nmap is a must-have tool for ethical hackers. You can use Nmap to protect your network. There are a bunch of Nmap alternatives available in the market. But it has already set the benchmark. Security teams of different organizations and network experts often use Nmap to find commonly abused protocols like RMI (Remote Method Invocation) and HTTP. Also, securities companies use this software to inspect the attack their systems can potentially face and find out what weaknesses hackers could exploit.
Bonus Tip: If you want to learn more about don’t forget to check Nmap’s official website.
Frequently Asked Questions on Nmap.
- What is Nmap used for?
Nmap or network mapper is an open-source network scanning tool that is popularly used by network administrators, hackers, and cyber security experts to map networks.
- What are the features of Nmap?
Network exploration, security auditing, vulnerability scanning, ping sweeps, host discovery, OS, and version detection are some features of network mapper(Nmap).
- Why do hackers use Nmap?
To exploit the vulnerabilities of the system and get access to uncontrolled ports of the system, hackers use Nmap.
- Is it legal to use Nmap?
Yes, it’s completely legal and totally safe to use Nmap until and unless you are not committing any crime. For more information, you can check the policy of your country.
